Bobbins look like the most generic part in sewing. Little plastic discs, sold in bags of twenty, apparently identical. Then you drop one from the bargain bag into your machine and the stitching goes wrong in a way that makes no sense: uneven tension, thread nesting underneath, a rattling sound from the bobbin area, or the bobbin simply will not sit right in the case.
The reason is that bobbins come in classes with different dimensions, and a difference of a millimeter or two is enough to break the relationship between the bobbin, the case and the hook. This page explains the classes you will meet on home machines, what separates them, and how to tell which one your machine takes.
This article contains affiliate links. If you buy through them, we may earn a commission at no extra cost to you. Learn more.
Quick Answer
What are the different sewing machine bobbin classes?
- Class 15, also called Style A, is the common home machine bobbin. Sewing Parts Online gives it as roughly 20.3 mm across and about 11.7 mm wide, with two flat sides.
- Class L is the same diameter, about 20.3 mm, but narrower at roughly 8.9 mm, so it holds less thread.
- Class M is the big one, around 24.9 mm across and about 10.7 mm wide, and belongs on long arm and heavy industrial machines.
- Metal and plastic versions of the same class are not automatically interchangeable, because weight changes how the bobbin spins.
Bottom line: the class is a size, not a brand. Find your class in the manual once, write it on a sticker, and buy by class from then on.
Why a Bobbin Class Exists at All
The bobbin does not just hold thread. It sits inside a case or a race that is machined to a specific diameter and width, and the thread comes off it under a tension set by a tiny spring. Change the size of the bobbin and you change the clearance, the spin and therefore the tension, all at once.
That is why a bobbin that is one millimeter too wide binds, and one that is too narrow rattles and lets thread escape past the spring. Neither of those reads as a bobbin problem when you are looking at a bad stitch on the top of the fabric.
Class, Style and Part Number
The same bobbin gets described three ways: a class number such as Class 15, a style letter such as Style A, and a manufacturer part number. They are not competing systems, just different labels used by machine makers, notions brands and parts retailers. The class is the one worth memorizing.
The Classes You Will Actually Meet
Three classes cover almost everything a home sewer encounters, and a fourth turns up on older Singer machines. The dimensions below are the ones parts retailers publish for each class, and the small differences are exactly why substitution goes wrong.
| Class | Diameter | Width | Where you find it |
|---|---|---|---|
| Class 15 (Style A) | About 20.3 mm | About 11.7 mm | Most modern home machines, drop in and front load |
| Class L | About 20.3 mm | About 8.9 mm | Many mid arm and some domestic quilting machines |
| Class M | About 24.9 mm | About 10.7 mm | Long arm quilting and heavy industrial machines |
| Class 66 | About 20.3 mm | Similar to Class 15 | Older Singer models, with a curved side profile |
The Class 15, L and M measurements come from the bobbin size references published by sewing parts retailers including Sewing Parts Online and Superior Threads. Class 66 is listed with the same footprint as Class 15 but a rounded rather than flat side wall, which is the detail that stops the two from swapping.
Class 15 and Class L Look the Same and Are Not
These two are the pair that causes the most trouble, because they share a diameter and differ only in width. Superior Threads describes the L style as the same diameter as the Class 15 but narrower, which means an L bobbin will physically drop into a Class 15 machine while a Class 15 bobbin is too wide to fit an L machine.
Physically fitting is not the same as working properly. A narrower bobbin in a wider case sits with slack, spins unevenly and holds less thread, so you get inconsistent bobbin tension and more frequent refilling. Use the class your manual names rather than the one that happens to slide in.
Plastic, Metal and Prewound
Within one class you will find plastic, aluminum and steel bobbins, plus prewound bobbins sold already filled. Weight changes how quickly a bobbin starts and stops spinning, which changes the effective tension, so a machine set up around a light plastic bobbin can behave differently with a heavy metal one of the same class.
The Prewound Question
Prewound bobbins are wound tighter and more evenly than most people manage by hand, and quilters use them heavily for that reason. The catch is that some are sized very slightly differently, some have a cardboard or paper side that can shed, and some machines with a bobbin sensor do not read them. Try one before you buy a box.
Whichever you use, do not mix bobbin types in the middle of a project, because the tension shift shows up as a stripe of slightly different stitching. If you are chasing an uneven stitch already, the checks in bobbin tension come before any purchase.
How Bobbins Cause Problems That Look Like Something Else
A wrong or damaged bobbin rarely announces itself. It shows up as a thread nest under the fabric, a loose looping stitch on the underside, thread that jams in the race, or a clicking sound as the machine runs. All four of those get blamed on tension, and all four can come from a cracked, warped or mismatched bobbin.
Check the obvious things first. A bobbin with a nick on the rim from being dropped will catch the thread on every rotation. A bobbin wound unevenly, with thread piled at one end, feeds in surges. Both are free to fix, and the winding technique that avoids the second one is covered in winding a bobbin.
Frequently Asked Questions
Are sewing machine bobbins universal? No. They come in classes with different diameters and widths, and using the wrong class changes the tension even when it appears to fit. Class 15, Class L and Class M are the three you will meet most often on home and quilting machines.
What bobbin does my machine use? The manual names it, usually in the accessories or specifications section, and the original bobbin that came in the box is the reference sample. Our page on which bobbin fits my machine walks through identifying it without the manual.
Can I use an L bobbin in a Class 15 machine? It will physically fit, since Superior Threads describes the L style as the same diameter but narrower. It is still the wrong part, because the bobbin sits with slack in the case, holds less thread and gives less consistent tension.
Is metal or plastic better? Neither is better in general, but you should use what your machine was designed for. Weight affects how the bobbin spins and therefore the tension, so a machine that ships with plastic bobbins can behave differently with metal ones of the same class.
Why does my bobbin thread keep nesting underneath? Usually the top thread is not seated in the tension discs, which happens when the machine is threaded with the presser foot down. Rethread with the foot up first, and only then look at the bobbin, the case and the winding.
How many bobbins should I own? Enough that you never unwind one to start a new color, which for most people means a dozen or more in the right class. They are cheap, and hunting for a free bobbin is how half wound colors end up tangled in a drawer.
The Bottom Line
Bobbins are sized parts, not generic discs, and the class is what you buy by. Class 15 for most home machines, Class L for many quilting machines, Class M for long arms, with the Class 15 and L pair being the trap because they share a diameter. Find your class once and stop guessing. Read next: which bobbin fits my machine, winding a bobbin properly, and our needle guide for the other consumable that decides your stitch.
